Wiring diagram for MX5 MK2.5

Hi All,

Can anyone share a wiring diagram for the 2.5 please.
I am looking for details on the door wiring and central locking function.
in my attempt to update MK2 to MK2.5 central locking using OEM parts.
I have found an excellent source for the MK2 - front page below;
Does similar exist for a MK2.5 including the connector pin-outs etc.

1 Like

This any good

nothing on the door / central locking in these :frowning_face:
thank you for sharing all the same

Try here - page 22

great … thank you for this, this helps a huge amount.
it doesnt seem to include connector details for everything.

do you have another document that provides the door/body connector details?

Have a dig around here
https://mellens.net/mazda/

1 Like

NA NB NC ND WORKSHOP MANUALS

ALL MODELS WORKSHOP MANUALS

Why go through all that hassle, you will hit major issues as it is all connected to the alarm/immobilizer system, its not worth the headache .
Just install a good aftermarket remote central locking system , it is sooooooooooo much easier, we install loads , good kits can be bought for £30, installed and working in a morning.

https://www.ebay.co.uk/itm/161991806452
M-m
